Insteon Central Controller Hub

INS-HB-2245-222-WT
  • $124.99


The  Insteon Central Controller Hub gives you control over a huge family of connected devices, all from your smartphone and tablet. You can create customized scenes, schedule on and off times by sunrise, sunset or time of day, plus control your Insteon devices and get status updates and get notifications on your smartphone. You can easily expand your Insteon system by adding any number of Insteon devices including Insteon cameras, plug-in and wire-in modules.

Features

  • Control all your devices from one place
    The Insteon Central Controller Hub gives you control over a huge family of connected devices, all from your smartphone and tablet.
  • Set customized scenes
    You can create customized scenes to streamline and automate your daily routine activities, such as your wakeup or bedtime routine.
  • Set schedules
    You can set schedules for individual devices or scenes or schedule on and off times by sunrise, sunset or time of day, so your devices work according to your schedule and routine.
  • Get Instant Alerts
    You can get status updates and instant alerts from sensors for things like motion, water leaks and doors opening, so you always know what's happening at home.
  • Voice Control
    The Insteon Central Controller Hub works with Amazon Echo and Dot for hands-free voice control.

COMPATIBILITY

Works with

The Insteon Hub works with Amazon Echo and Dot for voice control. Plus the Insteon Hub also supports Stringify which lets it integrate with other manufacturers including Ring, Honeywell, Logitech and more.

SPECS

Technical Specifications

  • Manufacturer: Insteon
  • Manufacturer Product No.: 2245-222
  • UPC: 813922013498
  • Patent No.: Protected under US and Foreign Patents (see www.insteon.com/patents)
  • Manufacturer Warranty: 2 Years
  • Audio Alert: Beeper, can be disabled through software
  • Local Control: No
  • Setup Memory: Non-volatile EEPROM
  • Status LED: Red / Green LED
  • Insteon Device Category: 0x03
  • Insteon Device Subcategory: 0x33 North America
  • Insteon Links: 992
  • Insteon Messages Repeated: Yes
  • Insteon Minimum Receive Level: 10 mV
  • Insteon Minimum Transmit Level: 3.2 Vpp into 5 Ohms
  • Insteon Powerline Device: Yes
  • Insteon Powerline Frequency: 131.65KHz
  • Insteon RF Device: Yes
  • Maximum Controlled Scenes: 256
  • Maximum Scene Memberships: 400
  • Multi-Link Support: Yes
  • Multi-Unlink Support: Yes
  • RF Beacon: Yes
  • Radio Frequency: 915 MHz
  • Radio Frequency Range: Up to 250 Ft. (Depending on your home’s construction)
  • Scene Commands Supported as Controller:
    • On, Off
    • Fast On, Fast Off
    • Begin Brighten, Begin Dim
    • End Brighten, End Dim
  • Scene Commands Supported as Responder: None
  • Beep on Button Press: No
  • Beeper: Yes
  • Enclosure Material: UV stabalized plastic
  • Mounting: Tabletop or Wall Mount
  • Operating Environment: Indoors
  • Operating Humidity Range: 0-90% relative humidity, non-condensing
  • Operating Temperature Range:
    • 32° to 104° F
    • 0° to 40° C
  • Set Button: Yes
  • Storage Temperature Range:
    • -4° to 158° F
    • -20° to 70° C
  • Weight: 5.2 oz (148 g)
  • Power Consumption: <0.75 Watts
  • Supply Voltage: No
  • Surge Resistance: Surges over 1000 Watts
  • Power Connector: IEC C8
  • Certification:
    • FCC ID Part 15B & 15C
    • IC RSS-219 Issue 8
    • Intertek ETL

INSTALLATION

Installation Guide

Quick Start Guide
